I went down a rabbit hole trying to add a “favicon” (Web page icon) to an ESP32 web server project.
No one seems to have a complete answer, so here you go!
UPDATE: After I clicked “Publish” on the original version of this article, I started running in to all sorts of problems with my ESP32.
This sent me even deeper in to the rabbit hole, but I ultimately found a good solution.
Here is a step-by-step walk-through (UPDATED).
Table of Contents
Summary
Building a web server on ESP32 is super simple, and is a great way to build a quick and dirty UI for most projects. In fact, I’m using ESP32 as the basis for v2 of my gate opener web interface.
HOWEVER, when you open the site in a browser, it makes a request for favicon, which is the “Favorite” icon – the website’s icon that will also be displayed in your bookmarks (used to be called “favorites”) list.
Since there are no files, the request to “/favicon.ico” fails with 404.
I don’t know why this bugged me, LOL! But I thought about it a bit and decided I wanted an icon.
Step by Step Solution (SVG)
Overview – add an icon <LINK> pointing to a SVG file. Then add a webserver handler to serve the SVG file.
SVG is a text-based, vector-based format.
- Go design / draw / photograph your website icon. Save as or convert to SVG format. Save as favicon.svg.h.
- Add favicon.svg.h to your project.
- Include favicon.svg.1 from your INO file:
#include "favicon.svg.h"
- Edit favicon.svg.h to turn it in to a c variable declaration:
const String favicon_svg = F(R"=====(<?xml version="1.0" encoding="UTF-8"?> <!DOCTYPE svg PUBLIC "-//W3C//DTD SVG 1.1//EN" "http://www.w3.org/Graphics/SVG/1.1/DTD/svg11.dtd"> <svg version="1.2" width="152.4mm" height="152.4mm" viewBox="0 0 15240 15240" preserveAspectRatio="xMidYMid" fill-rule="evenodd" stroke-width="28.222" stroke-linejoin="round" xmlns="http://www.w3.org/2000/svg" xmlns:ooo="http://xml.openoffice.org/svg/export" xmlns:xlink="http://www.w3.org/1999/xlink" xmlns:presentation="http://sun.com/xmlns/staroffice/presentation" xmlns:smil="http://www.w3.org/2001/SMIL20/" xmlns:anim="urn:oasis:names:tc:opendocument:xmlns:animation:1.0" xml:space="preserve"> <defs class="ClipPathGroup"> <clipPath id="presentation_clip_path" clipPathUnits="userSpaceOnUse"> <rect x="0" y="0" width="15240" height="15240"/> </clipPath> <clipPath id="presentation_clip_path_shrink" clipPathUnits="userSpaceOnUse"> <rect x="15" y="15" width="15210" height="15210"/> </clipPath> </defs>
...
</g> </g> </svg> )=====");
Note: XML must begin ON THE SAME LINE as the variable declaration. If not, the browser complains about XML not starting on the first line. Cyan text above is the original SVG definition.
- Modify your HTML header to link to the SVG file:
<!DOCTYPE HTML>
<HTML><HEAD>
<TITLE>My App v1.0</TITLE>
<META http-equiv='refresh' content='$DELAY,.' />
<LINK rel="icon" href="/favicon.svg" type="image/svg+xcml">
</HEAD>
<BODY>
// your HTML here
</BODY>
</HTML>
- Create a server handler to serve out the referenced SVG file:
void setup(){
//*** Other setup code ***
//HTTP Server
server.on("/" , normal_handler); //this is your
server.on("/favicon.svg" , handleFavicon); //favicon handler
server.begin();
//*** Other setup code
}
...
void handleFavicon(void){
server.send(200,"image/svg+xml",favicon_svg);
}
The pay careful attention to the content types – unless everything is configured properly, the browser will refuse it. “favicon_svg” is the variable we are declaring in “favicon.svg.h”.
Why Inline PNG Did Not Pan Out
At first, things worked great. As I started adding more content, I realized that the ESP became increasingly unstable.
After MUCH troubleshooting, here is the problem:
- server.send() writes the ENTIRE document as a single string and sends it back to the client. There is probably a way to break this up in to two or more strings, and then store each in its own variable, but this is way more complicated than using server.send()
- As you build the HTML, every time you use a String function to concatenate or replace, behind the scenes it’s creating a NEW string and then copying all of the data from the other strings.
- With 3000 extra bytes of base64-encoded PNG in there, it was having to copy the icon over and over and over in memory just to serve up a simple application.
Using the code above and SVG format, the response to the client can be much more easily stored in a single variable without thousands of bytes of overhead. When the browser asks for favicon.svg, the extra handler we set up serves it directly from PROGMEM without even having to copy it. Well…maybe the server object copies it in to a buffer, not sure. But WE don’t have to copy it. So even though the client may request it repeatedly, the ESP just keeps serving the same static content, with no string manipulation required.
The other problem I think I was having with sending raw PNG is that I suspect server.send(), expecting a string, can’t handle binary data. Since SVG is explicitly text, it doesn’t have that problem with SVG.
Another nice thing about linking the SVG is that you can test it by going to http://[whateverYourESPipAddressIs]/favicon.svg – this should display the favicon in your browser.
OLD Step by Step Solution (Uses base64-encoded PNG)
Overview – add an icon <LINK> reference containing an inline, base64-encoded PNG to the document header.
- Go design / borrow / draw / photograph your website icon. 48×48 pixels is an appropriate resolution. Save as PNG format or convert to PNG. The rest of the steps assume the icon file is saved as favicon.png.
- Convert to base64.
base64 favicon.png > favicon.h
- Add favicon.h to your project. Be sure to add “include” to your main INO file:
#include "favicon.h"
- Edit the base64 file (favicon.h) to add a variable declaration and HTML syntax:
- Add favicon to the HTML header:
String html=""; html+="<!DOCTYPE HTML><HEAD>"; html+="<TITLE>My App!</TITLE>"; html+=favicon; html+="</HEAD>"; html+="<BODY>"; ...app code... html+="</BODY></HTML>"; //send html to client server.send(200,text/html,html);
Since the header of EVERY page must include the favicon link, I have my header declared statically, and do a string replace.
Here is the result:
Note:
- Correct icon in upper-left
- No failed call to favicon.ico
Stuff that DID NOT Work
I tried adding a server handler for /favicon.ico and then passing binary file data back to the client. This fails for some uknown reason. I tried multiple file formats and variable declaration formats, and honestly couldn’t get it to work.
The method above is simple and reliable. Unfortunately, it adds 4k to the payload on every page refresh, but that’s not a huge amount of overhead.
UPDATE: Add this to the list of stuff that did not work.
OLD Detailed Explanation (base64-encoded PNG)
Looking at the color-coded code sample above:
| Color | Meaning | |
|---|---|---|
| █ | c++ variable declaration. | |
| █ | c++ syntax for preformatted, multiliine string | |
| █ | HTML syntax | |
| █ | base64-encoded favicon.png |
C declaration:
- “favicon” is declared as a String type.
- “const” is used because the string is immutable (non-variable variable)
- “F( )” function is specific to Arduino. This keeps the string value in non-volatile (PROGMEM) memory rather than copying to RAM.
Preformatted String:
- “R” combined with “=====(” tells C that this is a multiline (pre-formatted) string constant.
- The string constant ends with )=====”
- “=====” can be any 5 character string literal which book-ends the string constant.
- For example, “RABCDEF(String Constant)ABCDEF” works the same as “R=====(String Constant)=====”
- PHP syntax is similar.
HTML syntax:
- <LINK> tag is a general-purpose mechanism for including content from another file.
- “rel” tells the browser what KIND of link, in this case “icon”.
- “type” reiterates the content-type of the linked file.
- “href” points to the location of the linked file. Normally, this would be a URL.
- However, “data:” tells the browser that the file’s data is inline.
- “image/x-icon” is the content type.
- “base64” specifies that the file’s data is encoded as base64.
- Everything after the comma “,” is the base64 data
Base64 encoding:
- Three 8-bit bytes of data are encoded as four 6-bit groupings
- Base64 uses ONLY printable characters and is meant to be completely portable across machine types and implementations.
- Uses characters “0-9”, “A-Z”, “a-z”, “/”, “+”, and “=”
- Used for any application where a binary file needs to be embedded in to a readable or printable file, including e-mail, HTML, PKI, and LDAP.
Conclusion
Having gone through this entire process TWICE now, once with PNG and once with SVG, it just reminds me that arbitrary standards sometimes make things WAY more difficult than they should be. For example, Chrome WILL ALWAYS cache a page, even if it’s supposed to be dynamic, even if you put cache-control headers in place. But it REFUSES to cache favicon.ico, which should be completely static. If this was not the case, I could have served up a static header that includes the favicon, then redirect to a dynamic page. But because of this flaw, the dynamic page will re-request the favicon, even though Chrome already has it in cache.
Thank you for reading, and I hope you find this helpful!
